  • #3347 Reply

    Glenn van As
    Spectator

    Hi folks: just wanted to post this for you. I had a very nervous lady who came in today for an amalgam replacement that I had found decay on it.

    I had diagnosed this in the summer but forgot why we were retreating it, on the BW I could see nothing but in the mouth clinically I could see a shadow with the scope at high mag on the ML of the amalgam.

    I opened it up and yikes alot of decay but also a large crack visible at 16X mag which was asymptomatic but you know that when the resin is done suddenly it becomes an issue when it never was before you started.

    I took the pics and then used the 980 diode to trough interproximally to coagulate and remove some tissue tags and then used the Erbium to etch the tubules and remove the smear layer.

    Final pic is of the finished restoration and patient chose to have tooth crowned because she has had several other teeth fracture on her with Cracked tooth syndrome, so she decided to treat this one pre-emptively.

    I think the scope helped me to diagnose the decay, spot the crack and help with the laser procedures.

    Finally I am showing you the same image of the tooth shot at 2.5X mag with the scope and then 16X mag to show you the difference in what one can see.

    ALl the best.

    Glenn

    Cracked and fractured tooth.jpg

    DSCN1431 edited.jpg

    DSCN1433 edited.jpg

    #10428 Reply

    ASI
    Spectator

    Hi Glenn,

    Would the Diagnodent give you an accurate reading of the decay below the amalgam interproximally?

    A strong case for the use of scope.

    Thanks again.

    Andrew

    #10426 Reply

    dkimmel
    Spectator

    Glenn you are busted big time. I was waiting for you to slip. I just sent Don Coluzzi an e-mail with the link to this site. He should be getting in touch with you any day now about how you activated the diode tip! You would think that Bob Barr has influenced you! smile.gif
    David

    #10429 Reply

    Glenn van As
    Spectator

    Haha David……now think things out clearly for a minute.

    Could it be its not activated but char from the other side of the box where I cut the tissue already……..

    AHHA……..correcto mundo. THe diode is ready to coagulate after cutting already the other side. It will coagulate by cutting again, but in all honesty if I wanted to coagulate I should NOT have initiated the tip.

    WHat you see is from the removal of tissue from the other side of the box when I thought…..hey I better shoot a photo.

    To do try coagulation instead of cutting it is a non contact procedure requiring no initiation

    Good eyes, but you STILL NEED A SCOPE.

    Off to the ada to sell more unknowling souls on the perils of practicing without a scope.

    JUST KIDDING.

    Glenn

    #10427 Reply

    Glenn – These pics are amazing! I’ve got a scope coming in about a month. I can’t wait to see so close. Thanks for placing posts so frequently. I appreciate your willingness to share.

    Kelly

    #10425 Reply

    dkimmel
    Spectator

    Glenn, I played with a scope this weekend. I am in trouble!!!!
    David
