    Ten year old male presented w/ fractured #8. Tooth is vital.

    Before

    Treatment consisted of minimal tooth preparation (beveling of cavo-surface margins) using OpusDuo Erbium 350mJ 12 Hz
    Air abrasion to prepared tooth margins and to clean internal surfaces of broken tooth fragment, 60 psi
    Acid etch tooth and broken fragment
    Bond w/ 3M Single bond, Filtek Flow Composite, position broken frament, light cure
    Finish and polish.

    Immediately after treatment



    No LA used.
    Tooth fragment was out over three days before bonding. Will have improved esthetic appearance after tooth rehydrates.
    Total treatment time under 30 minutes.

    #6951 Reply

    Really neat stuff Jeff……..Nice photos too.

    Thanks for posting.

    Glenn

    #6945 Reply

    dkimmel
    Spectator

    Jeff nice case. 12HZ is that in contact?

    #6947 Reply

    Benchwmer
    Spectator

    Used a 800 micron conical saphire contact tip for prep.
    Jeff

    #6944 Reply

    Anonymous
    Guest

    Just think how much easier it would have been if treated w/ a Waterlase!

    Sorry Jeff, couldn’t resist smile.gif

    #6948 Reply

    Benchwmer
    Spectator

    Post-op photo at 4 months.
    Tooth still vital.


    Jeff

    (Edited by Benchwmer at 11:39 am on April 21, 2005)

    #6946 Reply

    Now that’s the proof, Jeff. Love seeing some good post-op pics. Thanks!

    Kelly

    #6952 Reply

    Lee Allen
    Spectator

    Jeff,

    Nice results for the 10yr old. Have you had an opportunity to treat an incomplete Ellis Class 2 or 3 fracture?

    I have a new patient with an angular incomplete fracture in nearly the same place, cold sensitive, and not to pressure. What do you think of treating the fracture with an Erbium (low settings) and using a bonding agent with or without an enamel shade composite? I was hoping that the laser would affect the bacterial and protein comtamination of the fracture site and flow a low viscosity self-etching bisGMA to seal it. May be difficult to get the laser energy to affect the fracture surface without troughing, and questionable how far the bonding agent will penetrate.

    Just thinking out loud.

    What is your thinking and experience on this idea?

    #6949 Reply

    Benchwmer
    Spectator

    Lee,
    I still use Air Abrasion with the Erbium for such anterior bonding. Removes white residue after Erbium.
    To decontaminate, defocused pulsed Erbium, prepare tooth w/ AA. In this case I used a contact tip to bevel remaining enamel.
    I still use etch on Enamel on anterior teeth.
    I am using 3M Adper Bond for posterior restoratoins (CL I, II, V, VI) and pits and fissures, scrub into enamel for 15 seconds, thin w/ air, light cure 10 seconds (if pit and fissure don’t light cure until after flowable) apply flowable composite, then if needed layer w/ hybrid composites. I think the Adper Bond bonding agent is tinted and affects color on anteriors, so I still use clear Single Bond.
    Studies show Adper Bond same strength of bond with or w/o etch to enamel.
    The Erbium won’t craze like a bur.
    Some of my ideas.
    GL
    Jeff

    #6950 Reply

    Benchwmer
    Spectator

    Still vital and looking good going on 1 year


    Jeff
