  • #2734 Reply

    etienne
    Spectator

    Hi Guys
    This patient presented with pain associated with tooth #24. The tooth displayed class3 mobility as well as drainage of puss from the sulcus and an apical fistula.

    Pockets varying between 12mm and 3mm were measured surrounding the tooth. The patient mentioned a history of a gingival graft in the labial area of the tooth. A recent pulp extirpation had also been performed by another practitioner.

    I opened the pulp chamber, instrumented the tooth upto a #35 file, did a deep root scaling, used the Nd:YAG inside the root canal as well as inside the sulcus and splinted the tooth. I placed Ca(OH) inside the root canal. The patient has an anterior open bite.

    Five days later the patient was seen again.


    5day xray.jpg

    At the second appointment I removed the Ca(OH) and used the laser again inside the canal. I rinsed the canal with both NaOCl as well Chlorhexidine and replaced the Ca(OH). No drainage of puss was evident and the patient experienced no pain.

    Any thoughts?
    Take care
    Etienne

    #5591 Reply

    Robert Gregg DDS
    Spectator

    Greetings Etienne,

    Nice treatment!

    The appearance of the gingival tissues after FRP Nd:YAG lasing shows smart application of energy used–i.e. no recession. I’m thinking you used very little energy, on the order of 30 seconds for that result.

    While the tissue still has “issues”, you can always go back and treat again once they firm up and the inflamation has resolved some.

    How long between 1st and 2nd appts?

    What sort of antibiotics did you prescribe?

    Thanks,

    Bob

    #5579 Reply

    etienne
    Spectator

    Hi Bob
    Thanks! Yes, you are correct, there was so little bone that I wanted to treat it very gently.

    The pockets measured up to 12mm, so I do expect to need a few more treatments.

    The pictures were taken on a Monday and following Friday, so little time for healing. I am seeing her again two weeks after the previous appointment and plan to complete the root treatment then. I prescribed Augmentin 1000mg bd.

    How would you advise treating the lesion further? When would you go into the perio lesion again, taking into account that I am going to use the laser for the endo as well?

    I suppose for somebody like yourself with all your laser experience this stuff is boring ;)) I really appreciate your advice!

    Take care
    Etienne

    #5585 Reply

    Robert Gregg DDS
    Spectator

    Thanks Etienne,

    No, never boring……….

    Sounds good. I’m guessing you used 150usec, 20 hz, 3.0 watts for 30 seconds? Less power? What were your settings?

    You may not have to retreat that pocket again.

    The next time you numb the patient up, I would gently probe. If you meet the slighest resistance, don’t push. Unless or until there is BOP, or inflamation, I would not retreat to the base of the defect. Keep the gingiva clean and “closed”.

    I would just use the laser in the canal.

    If there is a pocket and/or BOP, I would treat as you did the first time.

    Good luck,

    Bob

    #5580 Reply

    etienne
    Spectator

    Hi Bob
    Good guess!! Actually it was 150usec, 20Hz, 4watt for 20sec.
    How long would you wait until you decide to evaluate? I am seeing the patient shortly (next week I think) to complete the endo, would you wait longer?
    If you have BOP or a pocket, would you retreat to the base again?
    What would you say were the chances of saving a tooth like this? 50%? 40% Just wondering.
    Take care
    Etienne

    #5592 Reply

    Robert Gregg DDS
    Spectator

    Hi Bob

    Good guess!! Actually it was 150usec, 20Hz, 4watt for 20sec.

    So about 40 Joules, which is well within the tissue tolerances for that tooth and defect size.  Very smart on your part.

    How long would you wait until you decide to evaluate?

    30 days for both the RCT and the perio pocket.

    I am seeing the patient shortly (next week I think) to complete the endo, would you wait longer?

    No, that’s OK.

    If you have BOP or a pocket, would you retreat to the base again?

    Yes, but not with force.

    What would you say were the chances of saving a tooth like this? 50%? 40% Just wondering.

    I’d tell the patient 50%, but I’m thinking more like 90%.

    Take care
    Etienne
    Good luck!

    Bob

    #5581 Reply

    etienne
    Spectator

    Hi Bob
    Thanks very much for your note. Do you truly think the chances of saving a tooth like that is as high as 90%? WOW!!

    On another note, do you think the same effect could be reliably achieved using another kind of laser? Say for instance a diode?

    My gut feel is that the difference in wavelength is not that important but the difference in gated pulse vs free running pulse is crucial. What are your thoughts regarding this?
    Thanks!
    Take care
    Etienne

    #5586 Reply

    Robert Gregg DDS
    Spectator

    Hi Bob

    Thanks very much for your note. Do you truly think the chances of saving a tooth like that is as high as 90%? WOW!!

    Yes.

    On another note, do you think the same effect could be reliably achieved using another kind of laser? Say for instance a diode?

    No, not reliably……occasionally, not reliably.

    My gut feel is that the difference in wavelength is not that important but the difference in gated pulse vs free running pulse is crucial. What are your thoughts regarding this?

    I agree completely

    Thanks!

    Take care

    Etienne

    Thanks, you too.

    Bob

    #5582 Reply

    etienne
    Spectator

    Hi Bob
    So the peak power value is the important thing if I have this correct. Squeezing the same amount of energy into a shorter pulse, with assosiated long pulse delay (thermal relaxation time) is what is helping us here?
    Is there an ideal correlation between pulse delay and pulse energy and total energy for different situations, say endo, perio etc?
    Take care
    Etienne

    #5587 Reply

    Robert Gregg DDS
    Spectator

    Hi Bob

    So the peak power value is the important thing if I have this correct.

     Yes.

    Squeezing the same amount of energy into a shorter pulse, with assosiated long pulse delay (thermal relaxation time) is what is helping us here?

    Squeezing the same amount of average power into short pulse duration AND the pulse interval (say of 20 Hz) gives you the mathmatical ratio (duty cycle) between peak power and thermal relaxation, and the biological balance for what you did.

    The ratio of “on” to “off” time (duty cycle) is 0.3% if we use your PD of 150 divided by 50,000 usec in a second at 20 Hz.  So your laser is on for 0.3% and off for 99.7% yet delivers 1500 watts of peak power at 3.00 watt and 20Hz.

    Is there an ideal correlation between pulse delay and pulse energy and total energy for different situations, say endo, perio etc?

    Yes, we believe so.  Optimal combinations of parameters for achieving different clinical objectives?  Yes.

    Take care
    Etienne

    Thanks.  You too.  Bob

    #5583 Reply

    etienne
    Spectator

    Hi Guys
    I just saw this patient again when I completed the endo. This is the clinical picture:


    Here are the pics taken on 26May and today, 12June.


    It would be interesting seeing her again in a month or two.

    Any thoughts?
    Take care
    Etienne

    #5588 Reply

    Robert Gregg DDS
    Spectator

    Nice endo. Time will tell………

    Take care,

    Bob

    #5578 Reply

    etienne
    Spectator

    Thanks Bob! Yep, wish it would hurry up though…;)
    Take care
    Etienne

    #5589 Reply

    Robert Gregg DDS
    Spectator

    Etienne,

    Such a typical dentist!

    Instant gratification you want? LOL! We were all trained that way. Unlike physicians.

    Great things take time to realize. Like waiting for the sun to come up, then it’s always darkest right before dawn.

    Take care my friend,

    Bob

    #5584 Reply

    etienne
    Spectator

    Hi Bob
    How are you doing?

    If I used twice the power, would I have half the healing time??? 😉

    Just kidding of course.

    I was accused today (only half jokingly) of changing the dates on the pictures of these cases. The parameters of what can be done seem to be changing all the time.
    Take care
    Etienne
