Forums Laser Treatment Tips and Techniques Soft Tissue Procedures Exposure of canine for bracket

  • This topic is empty.
Viewing 12 posts - 1 through 12 (of 12 total)
  • Author
    Posts
  • #3335 Reply

    Glenn van As
    Spectator

    Did this one today before I left without anesthetic. Used TAC 20 topical with methylene Blue in it (just helps show it up a little bit better) and used the Er:YAG at 10 Hz and 40 mj with a 400 micron tip , no water but the assistant spraying a little air and water spray to keep patient comfortable. Quite a hunk of attached tissue we took off for the bracket (no photo of that as running behind).

    I do this alot now when the patient is all lined up but the canines are taking their time. Watch for the attached tissue though as you must be careful to not cut all of it away……….it is a problem then that will require a graft.

    Hope its interesting.

    glenn

    PS I used Astringident in an Ultradent syringe to get hemostasis quickly, could have used the diode too.

    Post and core cemented_Untitled_Page1_ 3_resize.jpg

    Post and core cemented_Untitled_Page2_ 3_resize.jpg

    #10320 Reply

    Glenn van As
    Spectator

    PS – check out how even at 10 Hz and 40 mj you can still get some iatrogenic notching on the enamel surface in the last photo at super high mag!!

    Cya

    Glenn

    #10314 Reply

    dkimmel
    Spectator

    Glenn that is a nice cut at 10Hz and 40mj. A lot smoother then I would have thought and no enamel ablation.
    Cool blue color!!

    #10321 Reply

    Glenn van As
    Spectator

    David, my thoughts are that if you are doing work without anesthetic (chemical) that you should try to keep the Hz below 20 (most patients cant tolerate it) and if the soft tissue work is done with anesthetic then 40-50Hz is fine.

    Magnification makes all the world of difference.

    Glenn

    #10317 Reply

    kapalua
    Spectator

    Beautiful job on that precise clean cut. I assume this could also be done with an Odyssey 810 nm laser? What is the best topical to use and where can I obtain it?

    Tom

    #10318 Reply

    Benchwmer
    Spectator

    Don’t try this with a Diode without local anesthetic.
    Jeff

    #10322 Reply

    Glenn van As
    Spectator

    You can do this Jeff but you need to use low settings with a very strong topical like
    EMLA, DRK liquid, TAC 20 etc.
    I use 0.5 -0.6 w CW with this but leave the topical on for a while and use high mag because the tissue will not cut quickly. I have done these with the diode but its not as fast but it is safer to not cut the tooth.

    Cya

    Glenn

    #10315 Reply

    kapalua
    Spectator

    Thanks Glenn, Where can I obtain those topical anesthetics?

    Tom

    #10319 Reply

    Benchwmer
    Spectator

    Glen,
    I would use a pulsed, Nd:YAG for such a case.
    I like being able to fire at the tissue w/o fear of damage to the tooth.
    I’ve used Dr K liquid, now I have my local phamacist make me the potion all kinds of flavors, but for me it never is a replacement for LA during a NdYAG gingival surgery procedure. Works for some small Erbium procedures.
    Glad it works so well for you.
    Jeff

    #10323 Reply

    Glenn van As
    Spectator

    Hi there Jeff and gang.

    EMLA is not available over the counter in the USA as it is in Canada.
    I use Topical TAC 20 which is Lido 20%, Tetracaine 4% and Phenlyephrine 2%.

    I get this from Professional Arts Pharmacy in Lafayette , LA.
    Ph. 888 237 4737

    I know Ron Kaminer has a DRK liquid that he helped make because he is fearful of sloughing and sytemic effects due to the lidocaine (hasnt happened to me) and he gets the liquid from

    Whites compounding pharmacy 318 631 2005

    I have cases I have done with the diode and it can be done, and I can post them but it takes longer and is more sensitive than the erbium. The erbium risks cutting the tooth. The NdYAG I dont have but it is a pulsed laser like the erbium and therefore can be less sensitive and because it is a soft tissue laser wont effect the enamel.

    Hope that helps

    Glenn

    #10316 Reply

    kapalua
    Spectator

    Hi Glenn,
    I found EMLA in the Southern Anesthesia and Surgical catalogue.
    Thanks for the info on the other topicals. I appreciate your help.

    #10324 Reply

    Glenn van As
    Spectator

    My pleasure Kapalua……..hope it helps and be judicious with the stronger topicals as they can burn if left too long.

    Gotta run……literally a marathon on Sunday so off to bed.

    Glenn
