Forums Laser Treatment Tips and Techniques Soft Tissue Procedures soft tissue smile enhancement

  • This topic is empty.
Viewing 9 posts - 1 through 9 (of 9 total)
  • Author
    Posts
  • #3292 Reply

    whitertth
    Spectator

    15 y/o girl post ortho ….4-6 mm pseudopockets on anteriors…EMLA topical for 6 minutes  Waterlase .75 watts 15 air 8 water. preop and immediate post op  No local needed, patient did not feel a thing…not too bad a result  what do u guys think?
    soft tissue 1.jpg

    soft tissue post.jpg

    #9911 Reply

    Glenn van As
    Spectator

    Hi Ron: nicely done, I bet the patient was very happy.

    It seems as OH was an issue due to the inflamed tissue on the maxillary anteriors and also the decalcification on the right lateral

    I blew up your image and had a look at it and although it got pixelated, it seemed to suggest that there was some etching on the centrals near the gingivectomy. Particularly on the right central.

    I always caution people that this can be caused even by .75W with erbium lasers if you angle the tip towards the tooth.

    What positiion did you hold the tip and did you shave the tissue back or cut it of in one chunk. Shaving it back you might avoid etching the tooth. Cutting it in one chunk will necessitate that you position the tip towards the tooth and then will cut the tooth.

    Dont get me wrong…….I think it is a wonderful result but in my mind for large gingivectomies the soft tissue lasers offer peace of mind with respect to non etching of tooth structure and with better control of hemostasis in these inflamed tissue cases like post ortho or gingival hyperplasia due to drugs.

    THanks for posting a very nice result, and have a look at the full sized pictures of the gingival aspect of the centrals to see if there is etching of the surface……

    THanks for sharing and its a great case.

    Glenn

    #9910 Reply

    Albodmd
    Spectator

    Nice case Ron, bet the patient was very happy. Did you use a soft tissue tip or the regular tip?
    Glenn,
    Do you do anything to the tooth if you inadvertently lase and etch it? Bonding agent or something?
    Regards,
    Al B

    #9914 Reply

    Swpmn
    Spectator

    Looks real nice Ron.

    How did you apply the EMLA?  Just dry tissue then paint on and or did you do something like soak a cotton roll or gauze in EMLA and let it sit up there for 6 minutes?

    Al

    (Edited by Swpmn at 1:47 pm on Aug. 14, 2003)

    #9908 Reply

    whitertth
    Spectator

    first sorry about the photos..mine r clear and when i reduced them thay got fuzzy …it has never happened before any suggestions….Glenn, to anser some questions…I angled the tip ( t4) to the tissue but i had to debulk it as well so then I angled in to the tooth…I may have etched it a bit as u say when i angled it towards the tooth…I dont think it will be a concern..
    Application of emla was on a cotton swab dry tissue 5 m inutes…I will post 2 weeks post ops next week

    #9912 Reply

    Glenn van As
    Spectator

    Again Ron , let me re- emphasize how nice a result it was. DOnt think for a minute that I am criticizing you.

    I know that by now you are an expert , but neophytes might now realize that this can happen. This is like the discussion that is occuring on Dental town with respect to the Waterlase being used for perio pocket reduction.

    I am just not a big fan of this wavelength ( or any erbium) being used as a panacea. Waterflow from the laser is cool , but I do think that the soft tissue wavelengths have a place in the practice of dentistry and am posting a case as we speak of a fibroma removal on the lateral aspect of the tongue.

    I could have done it very very fast with the erbium but the concern of hemostasis is a very real one and I was worried it might bleed horrifically.

    You are a master Ron with the erbium but I worry that the neophyte using the laser may get ALOT of etching if they angle the tip at a perpendicular angle to the facial aspect of the tooth or even a 45 degree angle.

    Nice case with EMLA only…..

    Congrats again on a fine result, and I just wanted to emphasize to use caution with the erbium around tooth structure ( ie pockets or gingivectomies ) as inadvertant damage to adjacent tissues is possible as the erbium wavelength is not selective for tissue only like the soft tissue lasers are.

    Glenn

    #9913 Reply

    Glenn van As
    Spectator

    HI Ron……..even though this is a soft tissue case, I wanted to show you a case I did yesterday for a Class V.

    I used 30 Hz and 30 mj without water for the soft tissue and then 30 Hz and 50 mj for the hard tissue with water . That works out to around 1.5W instead of .75 watts, but you can see the etching of the dentin is quite noticeable when you magnify the image with the scope.

    I wanted to show the angle of the tip on soft tissue and also show the angle for hard tissue.
    Hope this helps any new users out there.

    Keep the tip parallel to the tooth for soft tissue.

    Glenn

    Resize of Class V flowable.jpg

    Resize of Class V flowable pg 2.jpg

    #9907 Reply

    dkimmel
    Spectator

    Ron, Nice! You are using .75W with 15a/8w. I expect that this was in contact? Have you tried this at any higher settings in a defoucsed mode. I have been trying about 2W with 60a/30w as defoused. Hemostatus seems good ( except on the thin tissue) and it appears easier to thin. I can do a larger area and seem to have more control and the patients feel nothing.
    Glenn you are killing me with the scope!
    DAvid

    #9909 Reply

    whitertth
    Spectator

    yes David, 15/8…. As I remember now the patient had so profound anaesthesia, that I think my etching came from when I upped the power…For a few minutes to debulk the tissue iused 3 watts and the patient felt nothing and I bet thats where my etching came from as i was defocussed….1 week post op comming today so I will post the pic…anyone know why my pic on my computer is clear and when i shrink and post it is fuzzy? Anything I can do?
